Passat B6 & B7 Typ3C (2006-2015)

Instructions

1. Find the sleeve number on the diagram.
2. You'll find the number in the product name and description.
3. Have any doubts? Contact us—we'll help you choose.

Assembly Notes

• Fits vehicles up to 2013 chassis numbers WVWZZZ3CZD-000001.
• PFF85-501G is on car camber adjustable offering +/-0.5° of adjustment. For a nonadjustable bush, use PFF85-501.
• PFF85-502G is supplied with the bush pre-fitted into the new bracket, providing 1° of additional caster angle and anti-lift. For a bush without geometry adjustment, use PFF85-502.
• PFF85-504 fits vehicles up to the middle of 2008. Please check the picture of the 2 bushes to identify the insert you require.
• PFF85-505 fits vehicles with a 38mm diameter lower engine mount small bush. For 3.6 Ltr vehicles with a 42mm diameter bush, use PFF3-902.
• PFF85-704 fits vehicles from the middle of 2008 on. Please check the picture of the 2 bushes to identify the correct insert required.
• PFR85-524 PFR85-525 fit 4-wheel drive models only, except those with 3.6ltr engines.
• PFR85-527 PFR85-528 fit 4-wheel drive models only up to 28.5.2012.
• PFF85-531 is an insert designed to fill the voids of the original bush. This mount is found in various 2.0 FSi, 2.0 TFSi, 2.0 GTi, 2.0 Turbo V6 3.2 3.6 engines. Please check voids of your original mount are the same as the image shown for correct fitment.
