DBA 4000 series front brake disc set - T3 - DBA4654S-10 + DBA Brake Pads Xtreme Performance ECE R90 certified brake pads (Hawk HB453x.585) + HEL braided brake lines Subaru BRZ Forester Impreza RB320 WRX STi TOYOTA GT86

Set:
Front brake discs DBA 4000 series - T3 - DBA4654S-10
DBA Brake Pads Xtreme Performance ECE R90 certified (Hawk HB453x.585)
HEL braided brake lines - FREE!

Specification:

Suitable for street riding and occasional track riding
A perfectly matched and comprehensively tested brake disc and pad combination
DBA discs: Kangaroo Paw - 144 diamond and teardrop-shaped post ventilation system
DBA discs: T3 slots - additional number of degassing outlets allows friction gases to escape freely and improve pad grip
DBA discs: Thermal Stability Profiling (TSP) and increased disc durability under severe braking conditions
DBA brake pads: Semi-metallic carbon fiber friction material
DBA pads: GG friction class (0.45 medium mu from low to high temperatures)
DBA pads: Excellent performance at high temperatures
DBA pads: Optimum braking consistency up to 550℃ (1022℉)
Direct fit, requires no changes to the standard configuration

DBA 4000 series brake disc - T3

Catalog number: DBA4654S-10

Front axis

Recommended for: Weekend Warriors, Motorsport

Diameter [mm]: 326

Shield type: Kangaroo Paw

Number of holes: 10

Inner diameter [mm]: 58

Minimum thickness [mm]: 28

Thickness [mm]: 30

Height [mm]: 53

Pitch Circle [mm]: 100 & 114.3

Stage: Stage 4

Weight of 1 piece (kg): 10.2

DBA Brake Pads Xtreme Performance ECE R90 certified (Hawk HB453x.585)

Catalog number: DB1678XP

Front axis

Width [mm]: 131.8

Height [mm]: 77.3

Pad thickness [mm]: 14

FMSI: 7902-D1001

OEM: 26296FE100

ECE R90 Number: E11 R90-02A01584/49928

Weight of 1 piece (kg): 2.28

Over forty years of manufacturing experience and unrivaled expertise through research and development, the DBA brand has established itself as Australia's most successful manufacturer and world leader in brake disc manufacturing.

Thanks to continuous improvement of technology and a desire for innovation, DBA has managed to redefine and provide brake discs for a wide variety of vehicle applications and in a wide range of conditions. When it comes to brake discs, as with all safety components, there can be no shortcuts. Drivers around the world value DBA products for consistency, reliability and excellent performance. DBA guarantees this by engineering disc brakes that are significantly superior to standard and equivalent disc brakes. How? DBA aims to provide high quality, accuracy, the best metals and production equipment that enable the production of the highest quality brake discs.

Brake lines include:

• Teflon cable with steel braid
• Stainless steel tips
• Stainless steel screws (depending on model)
• Copper washers
• Instructions
• Lifetime warranty



HEL Performance cables are available in 13 different colors:

The set includes: 2x discs + pads + HEL cables

The set fits:

- TOYOTA\GT86\2.0 TRD 200BHP (2018-) Brake Pads: DB1678 Brake Caliper: Brembo

- Subaru\BRZ\2.0 tS 200BHP (2013-) Brake Pads: DB1678 Brake Caliper: Brembo

- Subaru\ Impreza\2.0 Turbo WRX STi 100 pcd (2002-2005) Brake Pads: DB1678 Brake Caliper: Brembo

- Subaru\ Impreza\2.0 Turbo WRX STi 114 pcd (2005-2006) Brake Pads: DB1678 Brake Caliper: Brembo

- Subaru\ Impreza RB320\2.5 Turbo (2006-2007) Brake Pads: DB1678 Brake Caliper: Brembo

- Subaru\WRX STi\2.5 Turbo 300BHP (2012-2017) Brake Pads: DB1678 Brake Caliper: Brembo

- Subaru\ Forester\2.5 Turbo STi 320BHP (2004-2008) Brake Pads: DB1678 Brake Caliper: Brembo

- Subaru\ Impreza\2.5 Turbo WRX STi (2006-2007) Brake Pads: DB1678 Brake Caliper: Brembo

- Subaru\ Impreza\2.5 Turbo WRX STi (2007-2012) Brake Pads: DB1678 Brake Caliper: Brembo
