Xtreme Performance Holden / HSV / Vauxhall - 230mm Rigid Ceramic Twin Plate Clutch Kit Incl Lightened Flywheel & CSC 1800Nm

Xtreme Performance Holden / HSV / Vauxhall - 230mm Rigid Ceramic Twin Plate Clutch Kit Incl Lightened Flywheel & CSC 1800Nm

Add to shopping list
Product code: KGM23631-2EL
Size
uniwersalny
2 271,09 €
incl. VAT / pc
Express checkout 1-Click(without registration)
Product unavailable, ask about the delivery date
Product unavailable, ask about the delivery date
Free and fast delivery
14 days for easy returns
This product is not available in a stationary store
Safe shopping
Product Description

Xtreme Motorsport Holden / HSV / Vauxhall - KGM23631-2EL

Index: KGM23631-2EL

Fits:

- HOLDEN CALAIS sedan (VE) 6.0 i V8 2006.08-2013.05 L77(364CUV8), L98(364CUV8) 5967 Petrol 270 kW 367 BHP
- HOLDEN CALAIS Wagon (VE) 6.0 i V8 2008.06-2013.05 L77(364CUV8), L98(364CUV8) 5967 Petrol 270 kW 367 BHP
- HOLDEN COMMODORE pick-up (VE) 6.0 Flex 2010.09-2013.04 L77(364CUV8) 5967 Petrol 260 kW 354 BHP
- HOLDEN COMMODORE pick-up (VE) 6.0 i V8 2007.09-2013.10 L77(364CUV8), L98(364CUV8) 5967 Petrol 270 kW 367 BHP
- HOLDEN COMMODORE sedan (VE) 6.0 i V8 2006.07-2013.05 L76, L77(364CUV8) 5967 Petrol 260 kW 354 BHP
- HOLDEN COMMODORE sedan (VE) 6.0 i V8 2006.07-2013.05 L77(364CUV8), L98(364CUV8) 5967 Petrol 270 kW 367 BHP
- HOLDEN COMMODORE Wagon (VE) 6.0 i V8 2006.07-2013.05 L76, L77(364CUV8) 5967 Petrol 260 kW 354 BHP
- HOLDEN COMMODORE Wagon (VE) 6.0 i V8 2008.04-2013.05 L77(364CUV8), L98(364CUV8) 5967 Petrol 270 kW 367 BHP
- HSV CLUBSPORT sedan (VE) 6.0 i V8 2006.08-2008.06 LS2(364CUV8) 5965 Petrol 307 kW 418 BHP
- HSV CLUBSPORT sedan (VE) 6.2 i V8 2008.04-2013.05 LS3(376CUV8) 6162 Petrol 317 kW 431 BHP
- HSV CLUBSPORT Wagon (VE) 6.2 i V8 2008.04-2013.05 LS3(376CUV8) 6162 Petrol 317 kW 431 BHP
- HSV GTS sedan (VE) 6.0 i V8 2006.08-2008.03 LS2(364CUV8) 5965 Petrol 307 kW 418 BHP
- HSV GTS sedan (VE) 6.2 i V8 2008.04-2010.10 LS3(376CUV8) 6162 Petrol 317 kW 431 BHP
- HSV GTS sedan (VE) 6.2 i V8 2010.10-2013.05 LS3(376CUV8) 6162 Petrol 325 kW 442 BHP
- HSV MALOO (VE) 6.0 i V8 2007.10-2008.03 LS2(364CUV8) 5965 Petrol 307 kW 418 BHP
- HSV MALOO (VE) 6.2 i V8 2008.04-2013.05 LS3(376CUV8) 6162 Petrol 317 kW 431 BHP
- HSV SENATOR sedan (VE) 6.0 i V8 2006.08-2008.03 LS2(364CUV8) 5965 Petrol 307 kW 418 BHP
- HSV SENATOR sedan (VE) 6.0 i V8 2006.08-2013.04 LS2(364CUV8) 5965 Petrol 297 kW 404 BHP
- HSV SENATOR sedan (VE) 6.2 i V8 2008.04-2013.05 LS3(376CUV8) 6162 Petrol 317 kW 431 BHP
- HSV W427 sedan (VE) 7.0 i V8 2008.07-2013.05 LS7 7009 Petrol 375 kW 510 BHP
- VAUXHALL VXR8 MALOO (E) 6.2 2008.04- LS3(376CUV8) 6162 Petrol 317 kW 431 BHP

Specs:
Clutch Disc Diameter (mm): 230

Clutch Disc Spline Count: 26

Clutch Disc Spline Diameter (mm): 28.6

Torque (Nm): 1830

Flywheel Step:

Design: Twin Plate

Tech Bulletins:

Clamp Load:

Recommended for: Motorsport

Xtreme Clutch 230mm twin plate kit
The Xtreme Clutch 230mm Race Clutch is available with either ceramic, organic or carbon friction materials, making these kits ideal for high horsepower and motorsport applications where a high heat capacity is required.

The Xtreme 230mm Race Clutch is the ultimate in clutch solutions with a range like no other. The 230mm range boasts a variety of kits to suit most high horsepower applications for street, circuit, drift or race use. The Xtreme 230mm Race Clutch has been designed, allowing for endless options with clutch operation with internal hydraulic options and pull-push conversions a factoring feature in the 230mm range.

Product Features:

  • Torque capacity 1800Nm
  • Kit contains everything you need for a successful installation + accessories
  • Push type billet alloy cover Low pedal effort
  • 4140 Chromoly pressure & intermediate plates
  • Chromoly adapter ring
  • Low inertia
  • Serviceable components
  • SFI certified design
Flat Diaphragm Rolled Diaphragm
Clamping Force 1300kg 1300kg
Torque Rating 1800Nm 1800Nm
Bearing Contact Diameter 65mm FLAT BEARING
Bearing Load (@ 48mm) 180kg 150kg
Release Travel Required 7mm 7mm
Assembly Mass (without flywheel) 8.30kg 8.30kg
Disc Set Static Mass 2.25kg 2.25kg
Friction Thickness New 8mm (0.315") 8mm (0.315")
Friction Thickness Worn 7.5mm (0.295") 7.5mm (0.295")

Brand
Xtreme Clutch
Entity responsible for this product in the EU
Ozparts B.V.More
Address: Weena 690Postal code: 3012CNCity: RotterdamCountry: HolandiaE-mail: customerservice@ozparts.eu
Symbol
KGM23631-2EL
